Thông số kỹ thuât:
Công nghệ quét: Quét ảnh
Độ phân giải quét: 1280x960 pixel
Tốc đô quét: 45fps
Đọc mã vạch 1D
Kết nối: Keyboard USB,RS232,USB Virtual com
Bảo hành: 12 tháng
Input voltage | 5 VDC ± 0.25V | |
Power | 5.00W (working); 0.40W (standby) | |
Current | 1000mA (working); 80mA (standby) | |
Image size | 1280× 960 pixels | |
Scanning angle | ±60°, ±40°, 360° (Skew, Pitch, Roll) | |
Decode capability | UPC-A, UPC-E, UPC-E1, EAN-13, EAN-8, ISBN (Bookland EAN), ISSN, Code 39, Code 39 full ASCII, Code 32, Trioptic Code 39, Interleaved 2 of 5, Industrial 2 of 5 (Discrete 2 of 5), Matrix 2 of 5, Codabar (NW7), Code 128, UCC/EAN 128 (GS1-128), ISBT 128, Code 93, Code 11 (USD-8), MSI/Plessey, UK/Plessey, China Post, China Finance, GS1 DataBar (formerly RSS) variants |
|
Indicator | Beeper, LED | |
Interface supported | Keyboard wedge, RS-232, USB Keyboard, USB virtual COM | |
Dimensions | Height × Width × Depth:152mm × 81mm × 144mm (without stand); 152mm × 112mm × 184mm (with stand); |
|
Weight | 543g (without stand, without cable); 810g (with stand , without cable); |
|
Cable | Straight 2.0m | |
Connector type | RJ-45 phone jack connector | |
Case material | PC+TPU | |
Temperature | 0° to 50°C (32° to 122°F), Operating; -40° to 70°C (-40° to 158°F), Storage | |
Humidity | 5% to 95% (non-condensing) | |
Programming method | Manual (reading special barcode) | |
Program upgrade | Online | |
Min. element width | 4mil, 1mil = 0.0254mm | |
Decoding depth | 4mil Code39 (9 chars): | 5mm-60mm |
5mil Code39 (3 chars): | 0mm-100mm | |
10mil Code39 (3 chars): | 0mm-148mm | |
13mil UPC (6 chars): | 0mm-170mm | |
15mil Code39 (1 chars): | 0mm-193mm | |
|
|
|
Safety | EMC: EN55022, EN55024 Electrical safety: EN60950-1 Photobiological safety: EN62471:2008 Illumination: 0~100,000LUX Protection class: IP52 Drop resistance: 1.5m (5.0ft) drops to concrete |
